Kingston 118CSS-5 Hard-Seat Safety Relief Valve - 3/4" MNPT, Select PSI

Kingston 118CSS-5 Hard-Seat Safety Relief Valve - 3/4" MNPT, Select PSI

Regular price $65.00 USD
Regular price Sale price $65.00 USD
Sale Sold out
Orders $25 or more ship free to the lower 48. Shipping details.
Condition : New

View full details

Product Description

Kingston 118CSS-5 Hard-Seat Safety Relief Valve

The Kingston 118CSS-5 is a high-flow brass safety relief valve with a 3/4" male NPT inlet for compressed-air pressure protection. Its stainless steel ball seats against a machined metal seat, and the pull ring permits manual testing. Choose the factory-set pressure required by your equipment.

Verified OEM Replacement

✓ Verified Replacement For: Ingersoll Rand 39331368IM — 90 PSI option only.

Ingersoll Rand’s PHE7 compressor instrument list identifies Kingston 118CSS-5-090 as the 90 PSIG regulation safety valve. Select 90 PSI for this replacement; this reference does not apply to the other pressure options.

Specifications

Manufacturer Kingston
Model 118CSS-5
Inlet connection 3/4" male NPT
Valve construction Brass body with stainless steel ball
Seat type Precision-machined hard seat (metal-to-metal)
Spring and pull ring Stainless steel
Discharge Vent to atmosphere
Available set pressures 50–300 PSIG; select the required pressure option
Series set-pressure range 25–300 PSIG
Maximum temperature 400°F (204°C)
Overall height 5-7/16 in.
Hex size 1-1/2 in.
Certification ASME code certified; UV and NB stamps
Pressure setting Factory set and sealed

Set Pressure and Air Flow Capacity

Air-flow capacities below are from Kingston’s 118CSS data sheet and apply to this connection size at the listed set pressure.

50 PSIG 256 SCFM
70 PSIG 336 SCFM
75 PSIG 357 SCFM
90 PSIG 417 SCFM
100 PSIG 458 SCFM
120 PSIG 538 SCFM
125 PSIG 559 SCFM
135 PSIG 599 SCFM
140 PSIG 619 SCFM
150 PSIG 659 SCFM
165 PSIG 720 SCFM
170 PSIG 740 SCFM
175 PSIG 760 SCFM
190 PSIG 821 SCFM
200 PSIG 861 SCFM
215 PSIG 922 SCFM
225 PSIG 962 SCFM
250 PSIG 1063 SCFM
275 PSIG 1164 SCFM
300 PSIG 1265 SCFM

Application and Selection

Match the inlet threads, required set pressure, relieving capacity and available installation clearance to the original valve and equipment requirements. The 400°F temperature rating supports applications where a high-temperature hard-seat valve is specified, including compressor discharge service within the valve’s ratings. Do not select a safety valve by thread size alone.

Hard-seat safety valves are not inherently bubble-tight and may exhibit slight leakage as operating pressure approaches the set pressure. Keep the factory pressure setting intact and follow the equipment manufacturer’s installation and testing instructions.

Kingston 118CSS technical data sheet (PDF)
