Conrader CTLB1234 In-Tank Check Valve - 1/2" FNPT x 3/4" MNPT, 1/8" Unloader

Conrader CTLB1234 In-Tank Check Valve - 1/2" FNPT x 3/4" MNPT, 1/8" Unloader

$29.95 USD
$29.95 USD
Sale Sold out
Orders $25 or more ship free to the lower 48. Shipping details.
Condition : New
Tell a friend
View full details

Product Description

Conrader CTLB1234 one-piece brass in-tank air compressor check valve with a 1/2" FNPT compressor-side inlet, 3/4" MNPT tank connection, and standard 1/8" NPT side port.

Specifications

Manufacturer part number CTLB1234
Conrader numeric reference 5859
Construction One-piece brass body
Compressor-side inlet 1/2" FNPT
Tank connection 3/4" MNPT
Side / unloader port 1/8" NPT
Rated flow 30 SCFM at 100 PSIG
Flow factor Cv 3.9
Cracking pressure 0.5 PSI
Maximum pressure 500 PSI
Maximum temperature 450°F

Existing CDI cross-reference: P5075T

Selection note: Verify compressor discharge size, receiver-tank thread, and unloader-port requirement before ordering.
