Conrader CTLB3812-TT In-Tank Check Valve - 3/8" FNPT x 1/2" MNPT, Dual 1/8" Ports

Conrader CTLB3812-TT In-Tank Check Valve - 3/8" FNPT x 1/2" MNPT, Dual 1/8" Ports

$29.95 USD
$29.95 USD
Sale Sold out
Orders $25 or more ship free to the lower 48. Shipping details.
Condition : New
Tell a friend
View full details

Product Description

Conrader CTLB3812-TT one-piece brass in-tank air compressor check valve with a 3/8" FNPT compressor-side inlet, 1/2" MNPT tank connection, and two 1/8" FNPT auxiliary/unloader ports.

Specifications

Manufacturer part number CTLB3812-TT
Construction One-piece brass body
Compressor-side inlet 3/8" FNPT
Tank connection 1/2" MNPT
Auxiliary / unloader ports Two 1/8" FNPT ports
Maximum flow 20 SCFM
Maximum pressure 500 PSI
Maximum temperature 450°F

Existing CDI cross-reference: P3850TT

Selection note: This is the double-tapped version. Verify that the application requires two 1/8" ports as well as the 3/8" FNPT inlet and 1/2" MNPT tank connection.
