WEG 00536OS1DCD56H-S 5 HP 56H Frame 230V Single-Phase ODP Compressor Motor

WEG 00536OS1DCD56H-S is a 5 HP single-phase compressor-duty motor for air compressor applications requiring a 56H-frame, high-speed ODP motor.

Specifications

• Horsepower: 5 HP
• Phase: Single phase
• Voltage: 230V
• Frequency: 60 Hz
• Frame: NEMA 56H
• Poles: 2
• Rated speed: 3440 RPM
• Synchronous speed: 3600 RPM
• Full-load amps: 20.3A
• Service factor: 1.00
• Enclosure: ODP (Open Drip Proof)
• Mounting: Foot mounted
• Shaft diameter: 5/8 in.
• Rotation: Reversible

Application / Selection

Designed for compressor-duty service where the equipment requires a 5 HP, 56H-frame, 230V single-phase ODP motor. No exact compressor make/model fitment is claimed without documentation. Verify horsepower, voltage, frame, shaft dimensions, mounting, RPM and rotation requirements before ordering.
